D36-LED Reflector Module (Gen 3) (Single Mode, Cree XHP50.2 LED)
US$50.00
D36 Generation 3 Reflector Module, XHP50.2 Version
(Tactical Single Mode) (7.2-18V Regulated Input)

-High Output Cree XHP50.2, K4 Bin LED (Max Output 2000 Lumens)
-7.2V to 18V Regulated Input for Maximum Flexibility
-Direct Thermal Copper MCPCB
-Fully Potted Internal Components
-Reverse Polarity Input Protection
-Over-Discharge Protection
-Driver Internals Thermally Potted
-Standard White Version
-Tactical Single Mode
-Constant Output
-Unique Reflector Design
-Precision Machined Aluminum Reflector
-High Temperature Resistant Light Orange Peel Coating
-Every Reflector Module is Pre-Focused for the Ultimate Spot


Compatible with:

Lumens Factory

Seraph SP-6, SP-9 with C to M Adaptor and M Mini Turbo Head Installed

(M Mini Turbo Head is also compatible with Surefire M Series Flashlights except M2)

Seraph SP-6, SP-9 with D36 Mini Turbo Head Installed

(D36 Mini Turbo Head is also compatible with Surefire P/C/Z/G Series Flashlights)

***The D36 Generation 2 Modules are NOT compatible with lights by Pila and Wolf-Eyes***

Runtime:

3 x CR123a Primaries: ~1 hour
3 x AW RCR123 (750mAh): ~1 hour
2 x AW 17500 (1100mAh): ~40 mins
4 x CR123a Primaries: ~ 1.2 hour
4 x AW RCR123 (750mAh): ~ 1.2 hour
2 x AW 17670 (1600mAh): ~1.5 hour
2 x AW 18650 (2900mAh): ~2 hours
6 x CR123a Primaries: ~2.3 hours
6 x AW RCR123 (750mAh): ~2 hours
